Description
Ultra-Fast Speed – Make full use of your network with Wi-Fi speeds up to 1167 Mbps (867 Mbps on the 5 GHz band and 300 Mbps on the 2.4 GHz band)
Bluetooth 4.2 – Achieve 2.5× faster speed and 10× more packet capacity than Bluetooth 4.0
Broad Wireless Range – Connect to your Wi-Fi in more parts of your home with two external high-gain antennas ensuring greater coverage and enhanced stability
Easy Installation – Plug the adapter into an available PCI-E slot to upgrade your desktop
| Model | Archer T5E |
| Interface | PCI Express |
| Dimensions | 4.8 × 3.3 × 0.85 in (120.8 × 83.2 × 21.5 mm) |
| Antenna | 2 Detachable External Antennas |
| Standards and Protocols | Bluetooth 4.2, Bluetooth 4.0 |
| Interface | USB 2.0 |
| Wireless Standards | IEEE 802.11b/g/n 2.4 GHz, IEEE 802.11a/n/ac 5 GHz |
| Signal Rate | 11ac: Up to 867 Mbps(dynamic) 11n: Up to 300 Mbps(dynamic) 11a: Up to 54 Mbps(dynamic) 2.4 GHz: 11n: Up to 300 Mbps(dynamic) 11g: Up to 54 Mbps(dynamic) 11b: Up to 11 Mbps(dynamic) |
| Reception Sensitivity | 5 GHz: 11ac HT80: -59.0dBm 11n HT40: -68.5dBm 11a 54Mbps: -73.5dBm 11a 6Mbps: -91dBm 2.4 GHz: 11n HT40: -69.5dBm 11g 54Mbps: -74dBm 11b 11Mbps: -87dBm |
| Transmit Power | 5 GHz: 21.5dBm(FCC) / 23dBm(CE) (EIRP) 2.4 GHz : 20.5dBm(FCC) / 20dBm(CE) (EIRP) |
| Wireless Modes | Infrastructure mode |
| Wireless Security | WEP, WPA/WPA2, WPA-PSK/WPA2-PSK |
| Modulation Technology | DBPSK, DQPSK, CCK, OFDM, 16-QAM, 64-QAM, 256-QAM |
| Certification | FCC, CE, RoHS |
| Package Contents | AC1200 Wi-Fi Bluetooth 4.2 PCIe Adapter Archer T5E Low-Profile and Full Height Brackets Quick Installation Guide Bluetooth USB Cable Resource CD |
| System Requirements | Windows 11/10/8.1/8/7 (32/64 bit) |
| Environment | Operating Temperature: 0℃~40℃ (32℉ ~104℉) Storage Temperature: -40℃~70℃ (-40℉ ~158℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing |
| Warranty | 2 Years limited warranty |
